Best Service Pipe Threading Machine Tool

Best service  pipe threading machine tool


QK series lathe are economical CNC horizontal lathe, which are not only suitable for oil pipe thread turning and pipe thread turning, but also widely used in all walks of life such as automotive, petroleum, military and other mechanical processing. The lathe has the advantages of high efficiency, low scrap rate, good consistency, etc.

Details

ITEM		UNIT	QKA1235
Capacities	External Dia. of pipes	340mm	260
	Swing over bed	mm	1100
	Swing over carriage	mm	730
	Max.length of workpiece	mm	1500/3000/5000
	Max.length of turning	mm	1300/2800/4800
	Span of guideway	mm	755
Spindle	Spindle nose		A2-20
	Taper hole of spindle		1:20
	Spindle bore	mm	355
	Top taper of spindle		morse 6
	Range of spindle speed	r/min	320
	Chuck	mm	800
Feed	Min. feed of X/Z-axis	mm	0.001/0.001
	Rapid of X/Z-axis	m/min	4/5
	Max. travel of X	mm	540
Turret	Turret type		V4 □300
	Section of tool shank	mm	40X40
	Indexing repeatability	mm	0.008
	Max.cutting force	N	29400
Tailstock	Dia. of tailstock	mm	160
	Travel of tailstovk	mm	300
	Taper hole of tailstock		morse 6
Others	Main power	kw	18.5
	Accuracy		IT6-IT7
	Roughness		Ra1.6
	Length	mm	4800/6300/8300
	Width	mm	2520
	Hight	mm	2120



Advantages

Easy operation                           high precision                         Reasonable structure
High rigidity whole bed                     Attractive price                       Maintenance simple

Screw and light bar

to connect the box with the slide box, and the movement and power of the feed box to the slide box, to make the slide box to get the longitudinal straight movement. The screw is specially designed for turning the various threads of the car. In other surfaces of the workpiece, the screw is used only with a bare bar and no screw.

Feed box

also called feeding box, feed movement are installed in the feed box shift gear, adjust its shift gear, can get the required feeding or pitch, through light poles or screw would transmit the motion to head for cutting.

Company profile

Anyang Xinheng Machine Tool Co. Ltd. have always been devoting to the research and manufacture of machine tools. We have LATHE, CNC LATHE, PIPE THREAD LATHE, SPHERE TURNING LATHE etc. We have the most professional research and development machines, who can meet all different requirements on technology and production. Welcome to contact us !

Product name	Type	Swing over bed	Max.length of workpiece
Ordinary lathe machine	CW6163/80/94	630~1640mm	50-12000mm
	CW6180/CW61100
	CW61100/125/160
Heavy duty lathe	CW61125/140/160	1250~2500mm(10t~32t)	3000-2000mm
	C61125/160/180/200
	C61160/200/250
Spherical lathe	C6555/95/160/180	550~1800mm	Dia.of spherical:550-1800mm
CNC lathe machine	CK6142/52/63/80/94	420~1600mm	750-6000mm
	CKB6180/100
	CK61100/125/160
CNC heavy duty lathe machine	CKH/CKHJ61125/160/200	1250~2500mm(16~63t)	3000-20000mm
	CK61160/200/220/250
CNC pipe thread lathe	QK1212/19	Dia.of pipes:120~460mm	750-2800mm
	QKP/QKA1226/46

Packing & Delivery

final delivering are based on the customer’s requirement.

Water-proof plastic film package with foam protection in each corner.

Solid Seaworthy Wood Box Package with Steel Belt.

Save space as much as possible for container loading.

Our Service

Pre-sale

Project system evaluation
Investment budget
Site measurement
Technical discussion
Supply professional drawing and lists.

In-sale

Quality guaranteed
Field service for equipment installation and training work
Acceptance and delivery.

After-sale

24h online response
Supplying spare parts at cost price
Regular return visit

Certifications




FAQ

  1.How long is your delivery time?

   Generally it is 15-60 days ,it is according to different machine model and configuration and order quantity.

   2.Payment term?

    30% deposit before we start producing.

   3.Could you please tell me the payment ways of your company?

    The payment way is general T/T.

   4.MOQ?

     1 set.

   5.Do you have CE or any other certificate?

    We have certificates,such as ISO, CE, The product Patent Certificate etc.

 Small Commen Sense----How to choose suitable lathe machine ?

 All of our machine tool equipments as client's requirement, for choose the most suitable lathe machine, please kindly providing the following inforamtion:

* How about the swing over bed?

 *What materials do you use for processing?

 *Your requirment for machine size:length,width and height?

 *What capacity do you need?

 *How long the workpiece needs to be processed?
